01CR2500
View 01
Intelligent Contraband Detector
CR2500
CR2500 is an intelligent contraband detector that identifies chemical, radiological and explosive or flammable substances in a single integrated device. It is used by security personnel to keep dangerous and prohibited items out of crowded stations, venues and event areas.
Overview
Product information at a glance
Screening at a busy entrance is a throughput problem as much as a detection one. CR2500 puts chemical warfare agents, drugs, explosive and flammable gases, liquids and solids, and radioactive items within reach of one instrument, so an operator is not choosing which threat to check for or changing device between checks.
When something is found, the device does more than alarm. It returns detailed information on the substance identified - toxicology, radiation thresholds, applications, and storage and disposal methods - which is what a responder needs in order to decide what happens next, and what most screening equipment leaves to a separate reference.
Evidence handling is built in: the detector captures photographs, stores data automatically, generates reports, and transmits encrypted data to a control centre over WiFi or Bluetooth. Detection is designed to be quick and accurate with low false-positive rates, and radioactive-substance detection is a particular strength.
Visual reference
Product gallery
02CR2500
View 02
03CR2500
View 03
Key information
Product features
Quick & accurate detection with low false positive rates
Strong radioactive substance detection ability
Easy to use
Can provide detailed information on the substances detected
Report generation and data transfer back to central control center
Encrypted data transfer
Technical data
Technical specifications
- Operating Principle
- Multi-sensor fusion technology
- Detected Objects
- Solids, liquids, powders, gases
- Detection Range
- Hazardous prohibited items such as radioactive materials, chemical agents, explosives, narcotics, and flammable and explosive materials, etc.
- Power Supply
- Built-in battery, can also be powered by 220V AC
- Overall Dimensions
- ≤ 400mm × 360mm × 550mm
- Weight
- <7kg
Application areas
Application areas
Case studies
Application cases
01Suspicious Package and Mailroom CBRNE Screening
An illustrative security scenario for evaluating a suspicious package through isolation, carefully selected CBRNE screening technologies and controlled escalation.
↗︎
02Integrated CBRNE Security for a Major International Event
An illustrative operating scenario for layered CBRNE screening, monitoring and coordination at a major international event. HT-Nova equipment has supported detection operations associated with major events in China.
↗︎
03Customs Prohibited Goods Inspection
Layered customs secondary inspection applies material identification, trace screening and radiation assessment according to the initial indicator and legal procedure.
↗︎
04Baggage CBRNE Security Inspection
A suspicious-baggage workflow moves a defined primary-screening alarm into controlled secondary inspection using hazard-specific methods and specialist escalation.
